(5) ‘DO’ Monitor & Force digital outputs
z If each digital inpupt is ON, it is highlighted and if OFF, it is not highlighted.
Example :
If you register RUN mode event to digital output 1, now operation mode of IPC5000 is RUN
mode, and you set digital output 1 to Normal type, this part will be displayed like below figure
3.6.2. If it is set as PWM, it can not be used for normal digital output type.
Fig. 3.6.2 Digital outputs ON/OFF status
z Force digital outputs(Only for test of digital outputs)
You can force digital outputs to ON or OFF by pressing the rectangle area of the digital output
number. The force digital outputs are available for this screen. But if you exit this screen, the
digital output will be OFF automatically.
z Selection of PWM Control output or normal digital output.
You can set digital output 1 and 2(Open Collector output) for Solid State Relay or Relay
output DO13 and DO14 to PWM output. IPC5000 has 4 PWM (Pulse Width Modulation) for
Time Proportional output. DO13 and DO14 mean Relay output terminals. In order to set
output type of digital output 1, 2, DO13, or DO14, like figure 3.6.3, push the small box, and
figure 3.6.4 will appear. You can only set this change in STOP mode.
Fig. 3.6.3 Digital output type selection
* DO-01display means Digital Output No. ‘01’.
DO
DO-02
DO-03 DO-04
DO-07 DO-08 DO-09
DO-12
DO-13 DO-14
DO-05
DO-10
DO-01
DO-06
DO-11
PWM
The button to go to screen(Fig 3.6.4) to
select whether it use Control output or
normal digital output, but DO13 and
DO14 don't support normal digital
output(for event output).
* DO-01display means Digital Output No. ‘01’.
DO
DO-02
DO-03 DO-04
DO-07 DO-08 DO-09
DO-12
DO-13 DO-14
DO-05
DO-10
DO-01
DO-06
DO-11
PWM
