Honeywell Notifier ID3000 User Manual

ID3000/ID2000 Fire Panel Configuration Tool Manual
Contents
iii 997-291, Version 3.05
November 2010
Contents
1 Introduction 1-1
1.1 PC Specification 1-2
1.2 Installation 1-2
1.3 Starting the Tool 1-3
1.3.1 Authentication Option 1-3
1.4 Connecting a PC to the Panel 1-4
1.5 Tool Overview and Menus 1-5
1.5.1 Tool Language Setting 1-5
1.5.2 Tool Window 1-5
1.5.3 File Menu 1-6
1.5.4 Panel Menu 1-7
1.5.5 Repeater Menu 1-9
1.5.6 View Menu 1-12
1.5.7 Edit Menu 1-12
1.5.8 Communications Menu 1-14
1.5.9 System Parameters Menu 1-17
1.5.10 Tools Menu 1-19
1.5.11 External Systems Menu 1-21
1.5.12 Help Menu 1-22
1.5.13 Toolbar Options 1-22
1.5.14 Loop Display 1-23
Page

Honeywell Notifier ID3000 Specifications

General

NAC Outputs	4
Power Supply	24 VDC
Display	LCD
Humidity Range	10% to 93% non-condensing
Type	Fire Alarm Control Panel
SLC Loops	1
Maximum Devices	Up to 198
Number of Loops	1
Max Devices per Loop	159
Max Devices per Panel	198
Communication Ports	RS-232, RS-485
Operating Temperature	0°C to 49°C (32°F to 120°F)
Number of Zones	Up to 198 intelligent zones
