ID3000/ID2000 Fire Panel Configuration Tool Manual
Control Matrix
4 - 4 997-291, Version 3.05
November 2010
Specific information for network
Outputs are applied only at the panel which
directly controls them (as stand-alone panels),
but inputs may be defined as originating at a
different panel. For example, to relate an output
operation on a device supervised by Slave 1
(on a Master/Slave network) to an input
originating at the Master, the Control Matrix
must be edited at Slave 1.
For network inputs, the definition ‘Device Co-
incidence’ depends upon the definition of the
input (see opposite).
Input Device Co-incidence
Specified zone Two sensors in alarm
on another panel in the specified zone
Any zone on Two sensors in alarm
any panel anywhere in the
network (including on
different panels)
