383
Figure 366 User group configuration page
4. Configure the user group as described in Table 119.
5. Click Apply.
Table 119 Configuration items
Item Descri
Group-name Specify a name for the user group.
Level
Select an authorization level for the user group: Visitor, Monitor, Configure, or
Management, in ascending order of priority.
VLAN
Specify the VLAN to be authorized to users of the user group after the users pass
authentication.
ACL
Specify the ACL to be used by the access device to control the access of users of the
user group after the users pass authentication.
User-profile
Specify the user profile for the user group.
This option does not take effect on this software version.
Allow Guest Accounts
Select this option to allow guest accounts to be added to the user group.
This option is selected for the system-defined user group system and cannot be
modified. However, this option does not take effect on this software version.
