3-82
Performance Tests
Multirate Optical Interfaces
Multirate Optical Interfaces
Specification (1310 nm Transmitter)
Specification (1550 nm Transmitter)
NOTE The Transmitter Wavelengths installed are dependent on HP 37718A/
37719A option.
Specification (Receiver)
Wavelength 1280 nm to 1330 nm (Typical 1310 nm)
Power Output +0.0 dBm to +3.0 dBm (Typical +1 dBm)
Line Coding NRZ
Safety Class Class 1, FDA 21 CFR Ch.1 1040.10 and EN 60825
Data Rates 51.84, 155.52, 622.08 or 2488.32 Mb/s (Nominal)
Wavelength 1530 nm to 1570 nm (Typical 1550 nm)
Power Output 0.0 dBm to +3.0 dBm (Typical +1dBm)
Line Coding NRZ
Safety Class Class 1, FDA 21 CFR Ch.1 1040.10 and EN 60825
Data Rates 51.84, 155.52, 622.08 or 2488.32 Mb/s (Nominal)
Wavelength 1200 nm to 1600 nm
Maximum Input Power
-8 dBm (for BER of 1.0E
-10
)
Line Coding NRZ
Sensitivity -34 dBm (STM-0/1/4, OC-1/3/12
-28 dBm Minimum (STM-16, OC-48)
(wavelength=1310/1550 nm, Modulation =
100%, Data=2
23
-1, BER=1.0E
-10
)
PMP Electrical Input 150mV pk-pk (Nominal) 51.84, 155.52 and
622.08 Mb/s only
PMP Impedance
Nominal 50Ω
