3-32
Performance Tests
PDH/DSn Receiver Equalization
PDH/DSn Receiver Equalization
Specifications
NOTE The Rates available are dependent on the HP 37718A/19A option
Description
The Receiver Equalization is checked by looping the transmitter output
to receiver input through a special Cable. This simulates the specified
cable loss at the rate under test. A BER measurement is run and a check
made for no errors in the results page.
Equipment Required
Rate Equalization
E1- 2.048 Mb/s 6dB for root f cable at 1/2 bit rate
E2 - 8.448 Mb/s 6dB for root f cable at 1/2 bit rate
E3 - 34.368 Mb/s 12dB for root f cable at 1/2 bit rate
E4 - 139.264 Mb/s 12dB for root f cable at 1/2 bit rate
DS1- 1.544 Mb/s Single range from DS1-LO to DSX -1
DS3 - 44.736 Mb/s Automatic equalization for up to 900
feet of root f cable.
Cable Simulator E4 80 metres of 8120-0049
Cable Simulator E3 120 metres of 8120-0049
Cable Simulator E2 80 metres of 8120-0049
Cable Simulator E1 120 metres of 8120-0049
Cable Simulator DS3 55 metres of 8120-0049
Cable Simulator DS1 80 metres of 8120-0049
110Ω/75Ω Balanced to
Unbalanced Converter
HP 15508B (Qty 2)
To Next Page
