Performance Tests
PDH/DSn Receiver Monitor Levels
PDH/DSn Receiver Monitor Levels
Specifications
NOTE The Rates available are dependent on the HP 37718A/19A option
Description
The signal from the HP 37718A/19A PDH Transmitter is applied to the
PDH Receiver after attenuating by an amount equal to the selected
Receiver Flat Loss plus the specified Cable Loss. The Flat Loss is
obtained from a 75Ω, attenuator kit. The Cable Loss is supplied by
inserting the correct Cable Simulators for each bit rate in the
attenuation path.
Equipment Required
Bit Rate Nominal
Loss
Equalization at 1/2 Bit
Rate
E1 - 2.048 Mb/s 20, 26, 30dB 3dB
E2 - 8.448 Mb/s 20, 26, 30dB 3dB
E3 - 34.368 Mb/s 20, 26dB 6dB
E4 - 139.264 Mb/s 20, 26dB 6dB
DS1 - 1.544 Mb/s 20, 26, 30dB 3dB
DS3 - 44.736 Mb/s 20, 26dB 6dB
Cable Simulator E4-M 40 metres of 8120-0049
Cable Simulator E3-M 60 metres of 8120-0049
Cable Simulator E2-M 40 metres of 8120-0049
Cable Simulator E1-M 60 metres of 8120-0049
Cable Simulator DS3 55 metres of 8120-0049
Cable Simulator DS1 80 metres of 8120-0049
75Ω Attenuator Kit HP 86213A
Type N/BNC adaptors HP 1250-1534 & -1528 (2 off each)
