1-8
General Information
Operators Maintenance
Operators Maintenance
WARNING NO OPERATOR SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED PERSONNEL. TO PREVENT
ELECTRICAL SHOCK DO NOT REMOVE COVERS.
Maintenance appropriate for the operator is:
• Cabinet cleaning
• Optical Connector Cleaning
• Power supply fuse replacement
• Ensure ventilating fan cover is clean.
Cleaning
Cabinet Cleaning
Clean the cabinet using a dry cloth only.
Optical Connector Cleaning
It is recommended that the optical connectors be cleaned at regular
intervals using the following materials:
CAUTION Do not insert any tool or object into the IN or OUT ports of the instrument
as damage to or contamination of the optical fibre may result.
1 Recall Default settings (STORED SETTINGS 0) and remove the
Description HP Part Number
Blow Brush 9300-1131
Isopropyl Alcohol 8500-5344
Lens Cleaning Paper 9300-0761
Adhesive Tape Kit 15475-68701
