Performance Tests
Performance Test Record
Performance Test Record
Note the test steps applicable are dependent on the instrument options and bit rates available.
Enter N/A if a test does not apply for your instrument .
Hewlett-Packard Model 37718/37719A 2.5 Gb/s Multirate
Communications Performance Analyzer
Location: Serial No.:
Tested by: Options:
Temperature: Certified by:
Humidity: Date:
Table 6 Performance Test Record
Page
No.
Test Description Result
Min Actual Max
Self Test
3-6 Step3 Confidence Tests Pass/Fail
3-7 Step 4 All Tests Pass/Fail
3-8 Step 3 1550nm Tests Pass/Fail
3-9 Step 3 DCC Tests Pass/Fail
PDH/DSn Internal
Transmitter Clock Accuracy
& Offset
3-11 Step 4: 2 Mb/s 1.023995 MHz 1.024005 MHz
Step 6: 2 Mb/s +50ppm 1.0240465 MHz 1.0240555 MHz
Step 8: 2 Mb/s -50ppm 1.023944 MHz 1.023953 MHz
3-12 Step 10: 8 Mb/s 4.223981 MHz 4.224019 MHz
Step 12: 8 Mb/s +30ppm 4.2241075 MHz 4.2242915 MHz
Step 14: 8 Mb/s -30ppm 4.223854 MHz 4.223892 MHz
