Performance Tests
PDH/DSn Transmitter Output
PDH/DSn Transmitter Output
Specification
NOTE The Rates available are dependent on the HP 37718A/19A option
Description
This test ensures the transmitter output level and pulse shape meet the
required specifications at all PDH/DSn rates. The Transmitter output is
connected to an Oscilloscope and the waveshape compared with the
predefined masks stored in the Oscilloscope memory. The signal levels
are also measured using the Oscilloscope.
Rate Level Waveshape
DSX-1
3.0V 20%
Fits mask T1.102-1993
DS1-LO As DSX-1 with 655' ABAM
Cable
DS3-HI 0.9V pk (nominal)
DSX-3 560mV pk (nominal) Fits mask T1.102-1993
DS3-900 330mV pk (nominal)
E1 Balanced
3.00V 10%
As per ITU rec G703
E1 Unbalanced
2.37V 10%
As per ITU rec G703
E2 Unbalanced
2.37V 10%
As per ITU rec G703
E3 Unbalanced
1.0V 10%
As per ITU rec G703
E4 Unbalanced
0.5V 10%
As per ITU rec G703
