CAUTION:
Populate hard drive bays with a SAS disk drive or a hard drive blank. Operating the server blade
without a SAS disk drive or disk drive blank causes improper airflow and cooling, which can lead to
thermal damage.
To replace the component, reverse the removal procedure.
DIMM baffle
CAUTION:
To avoid damage to the server blade and the enclosure, install the DIMM baffle in the proper
location after adding or replacing DIMMs. DIMM baffles that are missing or installed incorrectly can
compromise server blade and enclosure cooling.
Procedure
1. Power off the server blade and remove it from the server blade enclosure (Preparing the server
blade for servicing on page 112).
2. Remove the access panel (Access panel on page 117).
3. Pull the DIMM baffle straight up and out.
120 DIMM baffle
