NOTE:
A SAS drive in RAID mode is identified by "Scsi" in the device path A SAS drive in HBA mode is
identified by “SAS” in the device path.
NOTE:
Unlike parallel SCSI, you cannot correlate UEFI device paths to internal SAS disk drive bays with
SAS regardless of RAID/HBA mode. The UEFI device paths currently do not contain any
information that could be used to determine the physical location of the drives.
Device Path
format
Path example
PCIe root
bridge device
path node
UID
PcieRoot(0x30304352)/Pci(0x2,0x0)/
Pci(0x0,0x0)/Scsi(0x0,0x0)
(RAID mode)
PcieRoot(0x30304352)/Pci(0x2,0x0)/Pci(0x0,0x0)/
SAS(0x5000C500037688B9,0x0,0x1,NoTopology,0,0,0,0x0)
(HBA mode)
Hard drive
partition
device path
HD
(Partition,
Type,
Signature)
PcieRoot(0x30304352)/Pci(0x2,0x0)/
Pci(0x0,0x0)/Scsi(0x0,0x0)/
HD(1,GPT,27C34F01-9F1E-11DE-A0BB-AA000400FEFF)
(RAID mode)
PcieRoot(0x30304352)/Pci(0x2,0x0)/Pci(0x0,0x0)/
SAS(0x5000C500037688B9,0x0,0x1,NoTopology,0,0,0,0x0))/
HD(1,GPT,27C34F01-9F1E-11DE-A0BB-AA000400FEFF)
(HBA mode)
CD-ROM /
DVD-ROM
partition
device path
CDROM(E
ntry)
PcieRoot(0x30304352)/Pci(0x1D,0x7)/
USB(0x3,0x0)/CDROM(0x1)
NOTE:
Everything after "Scsi" or "SAS" in the output can vary because each SAS drive/partition is unique
Using the Boot Maintenance Manager
This menu allows you to change various boot options. The Boot Maintenance Manager Contains the
following submenus:
• Boot Options
• Driver Options
• Console Configuration
• Boot From File
• Set Boot Next Value
146 Using the Boot Maintenance Manager
