HP Integrity BL860c i4 User Manual

Mezzanine cards
Optional mezzanine cards enable additional network connectivity and provide Fibre Channel support. For
mezzanine card locations, see Server blade components on page 9.
Optional mezzanine cards are classified as Type I mezzanine cards and Type II mezzanine cards. The
card type determines where it can be installed in the server blade:
• Install Type I mezzanine cards on any mezzanine connector.
• Install Type II mezzanine cards only on Mezzanine 2 connector or Mezzanine 3 connector.
To install a card:
Procedure
1. Power off the server blade and remove it from the server blade enclosure (Preparing the server
blade for servicing on page 112).
2. Remove the access panel (Removing the access panel on page 43).
3. Remove the mezzanine connector cover.
54 Mezzanine cards
