12-4
Port Traffic Controls
Jumbo Frames
Configuring Jumbo Frame Operation
Overview
1. Determine the VLAN membership of the ports or trunks through which
you want the switch to accept inbound jumbo traffic. For operation with
GVRP enabled, refer to the GVRP topic under “Operating Rules”, above.
2. Ensure that the ports through which you want the switch to receive jumbo
frames are operating at least at gigabit speed. (Check the Mode field in the
output for the show interfaces brief < port-list > command.)
3. Use the jumbo command to enable jumbo frames on one or more VLANs
statically configured in the switch. (All ports belonging to a jumbo-
enabled VLAN can receive jumbo frames.
4. Execute write memory to save your configuration changes to the startup-
config file.
Command Page
show vlans 12-5
show vlans ports < port-list > 12-6
show vlans < vid > 12-7
jumbo 12-7
jumbo max-frame-size 12-7
