13-46
Configuring for Network Management Applications
LLDP (Link-Layer Discovery Protocol)
Displaying Port Configuration Details. This command displays the port-
specific configuration, including.
Figure 13-14. Example of Per-Port Configuration Display
Configuring Global LLDP Packet Controls
The commands in this section configure the aspects of LLDP operation that
apply the same to all ports in the switch.
Enabling or Disabling LLDP Operation on the Switch. Enabling LLDP
operation (the default) causes the switch to:
â– Use active, LLDP-enabled ports to transmit LLDP packets describing itself
to neighbor devices.
Syntax show lldp config < port-list >
Displays the LLDP port-specific configuration for all ports in
< port-list >, including which optional TLVs and any non-default
IP address that are included in the port’s outbound
advertisements. For information on the notification setting,
refer to “Configuring SNMP Notification Support” on page
13-50. For information on the other configurable settings
displayed by this command, refer to “Configuring Per-Port
Transmit and Receive Modes” on page 13-51.
The blank IpAddress field indicates that the
default IP address will be advertised from this
port. (Refer to page 13-52: “Configuring a Remote
Management Address for Outbound LLDP
Advertisements”
This field appears when dot3tlvenable is enabled
on the switch, which is the default setting.
These fields appear when medtlvenable is
enabled on the switch, which is the default
setting.
