B-27
Monitoring and Analyzing Switch Operation
Traffic Mirroring
Mirroring Configuration
Table B-1 shows the different types of mirroring that you can configure using
the CLI, Menu, and SNMP interfaces.
Table B-1. Mirroring Configuration Options
Monitoring
Interface and
Configuration
Level
Traffic Selection
Criteria
Traffic Direction
CLI Config Menu and Web
I/F Config
1
SNMP Config
Port(s)
Trunk(s)
All traffic Inbound only
Outbound only
Both directions
All traffic
(inbound and
outbound
combined)
Inbound only
Outbound only
Both directions
Classifier-based
policy (IPv4 or IPv6
traffic)
Inbound only Not available Not available
Switch
(global)
MAC source/
destination
address
Inbound only
Outbound only
Both directions
Not available Inbound only
Outbound only
Both directions
1
Configures only session 1, and only for local mirroring.
