HP ProLiant series User Manual

Error messages 121
Power management module board error codes
LED code: 7-1, 7-2, 7-3, 7-4, 7-5, 7-6, 7-7, 7-8, 7-9, 7-10, 7-11, 7-12, or 7-13
Location: Power management board
Action: Perform the following steps to resolve the problem. Stop when the problem is resolved.
1. Reseat the power management module.
2. Replace the power management module.
Power management module backplane error codes
LED code: 8-1, 8-2, 8-3, 8-4, 8-5, 8-6, 8-7, or 8-8
Location: Power management backplane
Action: Perform the following steps to resolve the problem. Stop when the problem is resolved.
1. Press the power management module reset button.
Unknown power management module error code
LED code: 19-1
Location: Unknown
Action: Perform the following steps to resolve the problem. Stop when the problem is resolved.
1. Press the power management module reset button.
Port 85 codes and iLO messages
Troubleshooting the system using port 85 codes
1. Locate the port 85 code display on the media board.
IMPORTANT: Be sure the port 84/85 switch is set to display port 85 codes on the media board.
2. Locate the code in the following table.
3. Reference the designated section in this guide for the appropriate troubleshooting steps.
For example, if the port 85 code displays "31h," refer to "Processor-related port 85 codes (on page
121)" for more information.
Port 85 code Description
3xh
Port 85 codes in this format indicate processor-related errors. Refer to "Processor-
related port 85 codes (on page 121)" for more information.
4xh
Port 85 codes in this format indicate memory-related errors. Refer to "Memory-
related port 85 codes (on page 122)" for more information.
6xh
Port 85 codes in this format indicate expansion board-related errors. Refer to
"Expansion board-related port 85 codes (on page 123)" for more information.
All other codes,
including 00h, 01h,
and 5xh
Port 85 codes in this range cover several areas. Refer to the section
"Miscellaneous port 85 codes (on page 123)" for more information.
Processor-related port 85 codes
Processor-related port 85 codes display on the media board in the format 3xh.
