Using the Embedded Web Server68
4. Enter the default user name and password.
NOTE: The default user name is Administrator and the default password is password. The
user name and password are case-sensitive.
5. Click OK. The Embedded Web Server interface opens with the View window displayed, as
shown in Figure 35.
Figure 35 Embedded Web Server interface—View window
Configure switch ports
Perform the procedure in this section to configure names and operating characteristics for the switch
ports.
To configure one or more ports:
1. Click Configure at the left side of the window. The Configure window opens with the Ports tab
displayed (Figure 36).
a. For each port to be configured, type a port name of 24 alphanumeric characters or less in
the associated Name field. The port name should identify the device to which the port is
attached.
b. Click the check box in the Blocked column to block or unblock a port (default is unblocked).
A check mark in the box indicates the port is blocked. Blocking a port prevents the attached
device from communicating with the switch. A blocked port continuously transmits the offline
sequence (OLS).
