Edge Switch 2/24 installation guide 99

Laser information

Three configurations of cards with fixed optics will be provided for each of the connector types: four

extended long-wave ports, four long-wave ports, and four short-wave ports.

Table 10 Laser specifications

–2 Gb

Part Number Transceivers on

UPM Card

Wave

Length

Media/

Distance

Standard

300836-B21

Long wave:

35 Km

4 Extended Long

wave

1310 nm 9/125 µm

Single-mode:

1 m–35 Km

100-SM-LL-L

300835-B21

Long wave:

10 Km

4 Long wave 1310 nm 9/125

µm

Single-mode:

1 m–10 Km

100-SM-LL-L

300834-B21

Short wave

4 Short wave 850 nm 50/125 µm

Multimode:

2 m–500 m

62.5/125 µm

Multimode:

1 m–200 m

100-M5-SN-I

HP StorageWorks Installation Guide
