HP V1910 Switch Series User Manual

139
Figure 125 The Modify VLAN tab
Table 53 Configuration items of modifying a VLAN
Item Descri
p
tion
Please select a VLAN to
modify
Select the VLAN to be modified.
Select a VLAN in the drop-down list. The VLANs available for selection are
created first and then selected on the page for selecting VLANs.
Modify Description
Modify the description string of the selected VLAN.
By default, the description string of a VLAN is its VLAN ID, such as VLAN 0001.
Select
membership
type
Untagged
Set the member type of the port to be modified in the VLAN.
The options include:
 Untagged—Indicates that the port sends the traffic of the VLAN after removing
the VLAN tag.
 Tagged—Indicates that the port sends the traffic of the VLAN without removing
the VLAN tag.
 Not A Member—Remove the port from the VLAN.
Tagged
Not A
Member
Select ports to be modified
and assigned to this VLAN
Select the ports to be modified in the selected VLAN.
Click one or more ports you want to modify on the chassis front panel.
If aggregate interfaces are configured on the device, the page displays a list of
aggregate interfaces below the chassis front panel, and you can select
aggregate interfaces from this list.
Return to VLAN configuration task list (approach I).
