HP V1910 Switch Series User Manual

76
Return to Local port mirroring configuration task list.
Configuring ports for a mirroring group
Select Device > Port Mirroring from the navigation tree and click Modify Port to enter the page for
configuring ports for a mirroring group, as shown in Figure 60.
Figure 60 The Modify Port tab
Table 22 Configuration items of configuring ports for a mirroring group
Item Descri
p
tion
Mirroring
Group ID
ID of the mirroring group to be configured
The available groups were created previously.
Port Type
Set the type of
the port to be
configured
Configure ports for a local mirroring group:
 Monitor Port: Configures the monitor ports for the local mirroring group.
 Mirror Port: Configures mirroring ports for the local mirroring group.
Stream
Orientation
Set the direction of the traffic monitored by the monitor port of the mirroring group
This configuration item is available when Mirror Port is selected is the Port Type drop-down
list.
 both: Mirrors both received and sent packets on mirroring ports.
 inbound: Mirrors only packets received by mirroring port.
 outbound: Mirrors only packets sent by mirroring ports.
Select port(s)
Click the ports to be configured on the chassis front panel. If aggregate interfaces are
configured on the device, the page displays a list of aggregate interfaces below the chassis
front panel. You can select aggregate interfaces from this list and configure them as
mirroring ports of a port mirroring group.
