HP V1910 Switch Series User Manual

395
Table 143 Port isolation group configuration items
Item Descri
p
tion
Config type
Specify the role of the port or ports in the isolation group.
 Isolate port: Assign the port or ports to the isolation group as an isolated port or
ports.
 Uplink-port: Assign the port to the isolation group as the uplink port.
IMPORTANT:
The uplink port is not supported on HP V1910 Switch Series.
Select port(s)
Select the port(s) you want to assign to the isolation group.
You can click ports on the chassis front panel for selection; if aggregation interfaces
are configured, they will be listed under the chassis panel for selection.
Port isolation group configuration example
Network requirements
 Campus network users Host A, Host B, and Host C are connected to GigabitEthernet 1/0/2,
GigabitEthernet 1/0/3, and GigabitEthernet 1/0/4 of Switch.
 Switch is connected to the Internet through GigabitEthernet 1/0/1.
 GigabitEthernet 1/0/1, GigabitEthernet 1/0/2, GigabitEthernet 1/0/3, and GigabitEthernet
1/0/4 belong to the same VLAN.
Configure Host A, Host B, and Host C to access the Internet and isolate them from each other.
Figure 374 Networking diagram for port isolation group configuration
Internet
Host A Host B Host C
GE1/0/3
GE1/0/2 GE1/0/4
GE1/0/1
Switch
Configuration procedure
# Assign GigabitEthernet 1/0/2, GigabitEthernet 1/0/3, and GigabitEthernet 1/0/4 to an isolation
group as isolated ports.
Select Security > Port Isolate Group from the navigation tree and in the page that appears, click the
Modify tab to enter the page shown in Figure 375.
