HP V1910 Switch Series User Manual

434
Table 171 Configuration items of configuring queue scheduling on a port
Item Descri
p
tion
WRR
Setup
WRR
Enable or disable the WRR queue scheduling mechanism on selected ports. Two
options are available:
 Enable—Enables WRR on selected ports.
 Not Set—Restores the default queuing algorithm on selected ports.
Queue
Select the queue to be configured.
Its value range is 0 to 7, but only 0 to 3 is user configurable and 4 to 7 are
reserved.
Group
Specify the group the current queue is to be assigned to.
This drop-down list is available after you select a queue ID. The following groups
are available for selection:
 SP—Assigns a queue to the SP group.
 1—Assigns a queue to WRR group 1.
 2—Assigns a queue to WRR group 2.
Weight
Set a weight for the current queue.
This option is available when group 1 or group 2 is selected.
Please select port(s) Click to select ports to be configured with queuing on the chassis front panel.
Return to Queue scheduling configuration task list.
Configuring line rate on a port
Select QoS > Line rate from the navigation tree and click the Setup tab to enter the line rate configuration
page, as shown in Figure 406.
Figure 406 The page for configuring line rate on a port
