30
A management IP address is the IP address of a VLAN interface, which can be used to access the device.
You can also set configure a VLAN interface and its IP address in the page you enter by selecting
Network > VLAN Interface. For more information, see the chapter “VLAN interface configuration.”
After finishing the configuration, click Next to enter the management IP address configuration page, as
shown in Figure 18.
Figure 18 Management IP address configuration page
Table 5 Management IP address configuration items
Item Descri
Select VLAN Interface
Select a VLAN interface.
Available VLAN interfaces are those configured in the page you enter by selecting
Network > VLAN Interface and selecting the Create tab.
Admin Status
Enable or disable the VLAN interface.
When errors occurred on the VLAN interface, disable the interface and then enable
the port to bring the port to work properly.
By default, the VLAN interface is down if no Ethernet ports in the VLAN is up. The
VLAN is in the up state if one or more ports in the VLAN are up.
IMPORTANT:
Disabling or enabling the VLAN interface does not affect the status of the Ethernet ports
in the VLAN. That is, the port status does not change with the VLAN interface status.
Configure IPv4
address
DHCP
Configure how the VLAN interface obtains an IPv4 address.
DHCP: Specifies the VLAN interface to obtain an IPv4 address by
DHCP.
BOOTP: Specifies the VLAN interface to obtain an IPv4 address
BOOTP
