InstallatIon
3-26 HPR800XD Auto Gas – 806500
Coolant hose set
(chiller to chiller-interface console)
6
6
Outlet
Inlet
Part no. Length
228540 4.5 m (15 ft)
228541 7.5 m (25 ft)
228542 15 m (50 ft)
Green band
on hose
Red band
on hose
Caution: Never use PTFE
tape on any joint
preparation.
