2050—Memory (SIMM)
Warning: Memory cards are sensitive to static discharge. See “Handling
ESD-Sensitive Parts” on page 4-41.
Adapter cards (2035) if applicable.
Riser card (if SIMMs located behind riser card).
Push out on the side clamps to release the module.
Pull the module up and out to remove.
Note: Run the Setup Utility after adding or removing memory.
Clamp
SIMM
Socket
SIMM
SIMM Socket
Figure 4-33. Memory SIMM
4-34
