SIMM Configurations—Type I-1
Factory-installed SIMMs are non-parity SIMMs. However, both parity and
non-parity industry standard SIMMs (2MB, 4MB, 8MB, 16MB, or 32MB) are
supported. When installing SIMMs, run the Setup Utility to clear XX62 or
164 error codes.
SIMMs can be installed in any order and size. See Table 5-2.
To verify the size of an unknown SIMM, do the following.
1. Power off the system unit.
2. Install the SIMM in J20, J21, or J22 and power on the system unit.
3. Read the SIMM memory count shown at the top left of the screen as the
system displays the POST icon.
Table 5-2 (Page 1 of 2). Gold-Contact SIMM Configurations (System
Board Type
I
-1)
Total
Memory
J22
(Bank 0)
J21
(Bank 1)
J20
(Bank 2)
2MB 2MB — —
4MB 2MB 2MB —
4MB 4MB — —
6MB 2MB 4MB —
6MB 2MB 2MB 2MB
8MB 4MB 4MB —
8MB 4MB 2MB 2MB
8MB 8MB — —
10MB 2MB 8MB —
10MB 4MB 4MB 2MB
12MB 2MB 2MB 8MB
12MB 4MB 4MB 4MB
12MB 4MB 8MB —
14MB 2MB 4MB 8MB
16MB 16MB — —
16MB 4MB 4MB 8MB
16MB 8MB 8MB —
18MB 2MB 8MB 8MB
20MB 4MB 8MB 8MB
20MB 4MB 16MB —
5-18
