Advanced Diagnostics Device Presence Test
001
DO ANY MESSAGES, ERROR CODES, BEEPS, OR SYMPTOMS
APPEAR?
Yes No
002
Go to Step 004.
003
Go to “Index of Symptoms, Messages, Error Codes, or Beeps” on
page 2-10. If directed here from the Index, go to Step 006.
004
(From step 002)
– Power off the system unit.
– Insert the Advanced Diagnostics diskette into drive A.
– Power on the system unit, and check for the following responses:
1. One short beep
2. Diagnostic screen
DID THE SYSTEM PRODUCE THE BEEP AND DIAGNOSTIC SCREEN?
Yes No
005
– Go to “Index of Symptoms, Messages, Error Codes, or Beeps” on
page 2-10.
006
(From page 2-38)
(From steps 003 and 007)
– Select 0 (SYSTEM CHECKOUT) on the diagnostic screen.
– Press Enter.
Compare the Installed Devices list with the actual options installed in the
system unit. (Remove the system unit cover if necessary to verify what
devices are installed.)
(Step 006 continues)
2-34
To Next Page
