Assembly 3: Machine Type 2168 System Unit -
Exterior (SL-I)
1
2
Asm– Part
Index Number Units Description
3–1 Top Cover Assembly with Bezel and
Pull-Down Door (Does not include
system base—see “Assembly 4:
Machine Type 2168 System Unit -
Interior (SL-I)” on page 7-8)
–1 42H0343 1 Machine Type 2168 Base model
(includes logo and labels)
–2 34G1861 1 Base Assembly
Parts Catalog 7-7
