Diagnostics for Factory-Installed Riser Card, Sound
Card, or Adapter Cards Not Supported by Advanced
Diagnostics
Note: While performing this check, you may need to enter and exit
Microsoft Windows several times. When instructed to select an icon
or button, double-click on the item with the mouse.
For more information about using Microsoft Windows, see the user’s
guide provided with the computer.
This diagnostics test is intended to be used only with factory-installed
adapter cards.
001
– Remove the Advanced Diagnostics diskette.
– Power off the system unit and wait 10 seconds.
– Power on the system unit.
IS A POST ERROR CODE DISPLAYED?
Yes No
002
Go to Step 004.
003
– Go to “Index of Symptoms, Messages, Error Codes, or Beeps” on
page 2-10.
004
(From step 002)
ARE ANY ERROR CODES DISPLAYED AFTER POST COMPLETES BUT
BEFORE MICROSOFT WINDOWS STARTS?
Yes No
005
Go to Step 007 on page 2-44.
006
Go to Step 011 on page 2-45.
Check Procedures 2-43
