6. Note the position of the cables connected to the logic card; then, disconnect them.
7. The logic card can now be set aside in a static-protective package.
Note: If the logic card is to be reinstalled, take precautions to avoid damage from static electricity. For
details about handling these devices, see “Handling static-sensitive devices” on page 27 and set
the logic card aside for future use. Otherwise, discard the logic card and see “Installing the logic
card” for information on how to install the new logic card.
Installing the logic card
This section provides the information needed to install the logic card in the a fiscal or fiscal ready printer.
A
B
Figure 29. Removing the logic card
Removing and replacing FRUs
56
SureMark Hardware Service
