Appendix C. Parts listing
This section contains FRU part number information.
How to use the FRU catalog
This parts listing contains reference drawings and a corresponding index for all field replaceable parts. The
index provides the part number, the quantity required (units), and a description of the part.
Listed below is additional information about the parts assembly index.
SIMILAR ASSEMBLIES
If two assemblies contain a majority of identical parts, they are broken down on the same list.
Common parts are shown by one index number. Parts specific to one or the other of the
assemblies are listed separately and identified by description.
AR (As Required) in the Units column indicates that the quantity is not the same for all machines.
NP (Non-Procurable) in the Units column indicates that the part is non-procurable and that the
individual parts or the next higher assembly should be ordered.
NR (Not Recommended) in the Units column indicates that the part is procurable, but not
recommended for field replacement, and that the next higher assembly should be ordered.
R (Restricted) in the Units column indicates the part has a restricted availability.
INDENTURE
The indenture is marked by a series of dots located before the parts description. The indenture
indicates the relationship of a part to the next higher assembly.
No Dot Main assembly
One Dot Detail parts of a main assembly
One Dot Subassembly of the main assembly
Two dots Detail part of a one-dot subassembly
Two dots Subassembly of a one-dot subassembly
Three dots Detail part of a two-dot subassembly
© Copyright IBM Corp. 2010 79
