4
RECEIVE AND TRANSMIT
4-4
Previous view
Operating CW (Continued)
About the CW reverse mode D
The CW reverse mode receives signals with a reverse
side CW carrier point similar to voice LSB and USB
modes.
Use when interfering signals are near a desired signal
and you want to reduce the interfering tone.
On the Mode selection screen, touch “CW” to select q
the CW mode.
After the CW mode is selected, touch “CW” again on w
the Mode selection screen to toggle between CW
and CW-R modes.
• Check that the interfering tone can be reduced.
About keying speed D
The transceiver’s internal electronic keyer speed can
be adjusted to between 6 and 48
wpm (words per min-
ute)
.
Push q
(C) to open the Key speed/CW pitch
adjustment display.
Rotate [M-CH] w
(L) clockwise to increase keying
speed; counterclockwise to decrease it.
Push e
(C) to close the display.
About CW pitch control D
The received CW audio pitch can be adjusted to suit
your preference without changing the operating fre-
quency.
Push q
(C) to open the Key speed/CW pitch
adjustment display.
Rotate [BANK] w
(L) to suit your preference.
• Adjustable from 300 to 900 Hz (in 5 Hz steps).
Push e
(C) to close the display.
Key speed adjustment
CW pitch adjustment
Carrier point
The CW carrier point is set to the LSB side by default,
the setting can be changed to USB side in the “CW
Normal Side” item of the “Function” Set mode. (p. 165)
(C) > Function > CW Normal Side
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch panel)
L
eft
R
ight
C
enter
D
isplay
BFO
CW-R mode (USB side)
BFO
Desired signal
CW mode (LSB side)
Interference
Desired signalInterference
