150
13
OTHER FUNCTIONS
N Tone/DTCS squelch
q Set the desired operating frequency on FM or FM-N
mode, CTCSS tone and DTCS code.
w Push and hold [TONE](7) for 1 sec. several times to acti-
vate the tone or DTCS squelch. (T SQL or DTCS)
• Subaudible tone encoder “T,” pocket beep (tone squelch)
“ST SQL,” tone squelch “T SQL,” DTCS beep “SDTCS,”
DTCS squelch “DTCS,” tone squelch reverse “T SQL-R,” DTCS
squelch reverse “DTCS-R” and no tone operation are activated
in order.
• Rotating [DIAL] while pushing [TONE](7) also selects the tone
functions.
e Operate the transceiver in the normal way.
r When the received signal includes a matching tone/code,
the squelch opens and the signal can be heard.
• When the received signal’s tone/code does not match, tone/
DTCS squelch does not open, however, the S-indicator shows
signal strength.
• To open the squelch manually, push and hold [SQL].
No tone operation Subaudible tone encoder
Tone squelchPocket beep
DTCS beep
DTCS squelch
Tone squelch (reverse) DTCS squelch (reverse)
