74
7
DV MODE OPERATION
N
Low-speed data communication
In addition to the digital voice communication, low-speed data
communication is available.
The optional OPC-1529R
DATA COMMUNICATION CABLE and
serial data communication software (purchase locally) are re-
quired in addition.
NOTE: Turn OFF "GPS-TX" (p. 138) in advance to operate
the low-speed data communication.
D Connection
Connect the transceiver to your PC using with the optional
OPC-1529R as illustrated below.
OPC-1529R
(optional)
to [DATA]
PC
D Low-speed data communication application
setting
Configure the low-speed data communication application as
follows.
• Port : The same COM port number as IC-E80D’s
• Baud rate : 9600/4800
bps (p. 127)
• Data : 8 bit
• Parity : None
• Stop : 1 bit
• Flow control : Xon/Xoff
D Low-speed data communication operation
NOTE: Confirm that in AUTO, the computer controls when
[PTT] is activated to send data and the user doesn’t have
to operate the radio.
q Set the current call signs, etc. as described in “Current call
sign setting” (p. 47), “Simplex operation in VFO” (p. 60) and “Re-
peater operation in VFO” (p. 62).
w Refer to the instructions of the low-speed data communica-
tion application.
e To transmit data
• At the same time as your voice audio, push and hold [PTT] to
transmit while sending data from the PC. Release [PTT] to re-
ceive.
• Under computer control, see Transmission condition setting at
right.
To Next Page
