RECEIVER SPECIFICA
TIONS
3.4
CHARGER SPECIFICA
TIONS
AIRBORNE BA
TTERY P
ACK
3.5
3.6
MODEL NUMBER
NER-600
TYPE
6-Channel/FM-ABC & W/Circuitry
FREQUENCY
50/53/72MHz
SENSITIVITY (Microseconds)
5µs Minimum
SELECTIVITY
8KHz/50dB
WEIGHT
(oz.)
1 oz.
SIZE
(in.) (W x L x H)
1.43 x 2.06 x .55
RECEIVER ANTENNA
39" For All Aircraft Frequencies
TYPE R600 FM
MODEL NUMBER
INPUT VOL
T
AGE
OUTPUT CURRENT
CHARGING TIME
NEC-211
AC 100-120V
50mAh Tx/50mAh Rx
15 Hours
NEC-222
AC 100-120V
50mAh Tx/150mAhRx
15 Hours
TYPE AIRPLANE
HELICOPTER
MODEL NUMBER
VOL
T
AGE
SIZE (in.) (W
x
L x
H)
WEIGHT (oz.)
4N-600
4.8V
2.24 x 0.59 x
2.05
3.3
4N-1000
4.8V
2.60 x 0.63
x
1.70
4.9
TYPE AIRPLANE
HELICOPTER
CHAPTER 3
:
SPECIFICA
TIONS
•
Introduction continued
12
XP652 MANUAL Introduction
11
13
Table of Contents
Default Chapter
4
Quick Start
4
Table of Contents
8
Introduction
9
Using this Manual
9
Features
9
Transmitter Features
9
Receiver Features
9
Servo Features
10
Servos
11
Specifications
11
System Specifications
11
Transmitter Specifications
11
Servo Specifications
11
Receiver Specifications
12
Charger Specifications
12
Airborne Battery Pack
12
Battery Charging
13
Transmitter/Receiver
13
Charger
13
Trainer System
14
II. Airplane Section
15
Transmitter Controls
15
Control Identification and Location
15
Receiver Channel Assignment/Transmitter Throttle ATL
15
Transmitter Rear
16
Control Stick Length Adjustment
17
Direct Servo Control (DSC)
17
Neck Strap Attachment
17
Connections
18
Installation Requirements
18
Key Input and Display
19
Battery Alarm and Display
19
Input Mode and Function
20
Normal Display
20
System Mode
20
Function Mode
21
Functions (System Mode)
22
Model Type Selection
22
Data Reset
23
Dual Rate Switch Selection
24
Wing Type Selection
25
Model Selection
27
Model Name Entry
28
Modulation Select
29
Fail-Safe/Hold
30
Fail-Safe (Z-PCM)
31
Fail-Safe (S-PCM)
33
Functions (Function Mode)
34
Servo Reversing
34
Dual Rate
35
Exponential
36
Sub-Trim
37
Travel Adjustment
38
Aileron to Rudder Mixing 39
39
Elevator to Flap Mixing 41
41
Differential 43
43
Flap to Elevator Offset Trim 44
44
Programmable Mixing (A,B,C)
45
Trim Offset
48
Data Sheets
51
III. Helicopter Section
52
Transmitter Controls
52
Control Identification and Location
52
Receiver Channel Assignment/Transmitter Throttle ATL
52
Transmitter Rear
53
Control Stick Length Adjustment
54
Direct Servo Control (DSC)
54
Neck Strap Attachment
54
Connections
55
Installation Requirements
55
Battery Alarm and Display
56
Key Input and Display
56
Input Mode and Function
57
Normal Display
57
System Mode
57
Function Mode
58
Functions (System Mode)
59
Model Type Selection
59
Data Reset
60
Dual Rate Switch Selection
61
Gear/Gyro Switch Selection
62
Model Selection
63
Model Name Entry
64
Modulation Select
65
Fail-Safe/Hold
66
Fail-Safe (Z-PCM)
66
Fail-Safe (S-PCM)
67
Functions (Function Mode)
70
Servo Reversing
70
Dual Rate
71
Exponential
72
Sub-Trim
73
Travel Adjustment
74
Throttle Hold
75
Pitch Curve
76
Accessing the Pitch Curve Function
76
Throttle Curve
77
Accessing the Throttle Curve Function
77
Revolution Mixing
78
Rudder Offset
79
Programmable Mixing (A)
80
Stunt Trim
83
CCPM Swashplate Mixing
84
Trim Offset Memory
86
Data Sheets
89
Ergo .32/.46 Initial Setup
89
Ergo .46 Initial Setup W/3D Pitch Curve
90
Ergo .60 Initial Setup
91
Blank Data Sheet
92
Important Information
93
General Notes
93
Daily Flight Checks
93
Warranty Coverage
94
Repair Service Instructions
94
Warranty and Service Information
94
Frequency Chart
