JR XP652 User Manual

62
XP652 MANUAL Helicopter
Accessing the Gear/Gyro Switch Selection Function
–
+
MODE
ENTER
CHANNEL INCREASE
CLEAR
DECREASE
Press the INCREASE or DECREASE
button to select the switch you prefer to use
for the operation of the gyro sensitivity.
Press the MODE button
until GER appears
on the screen.
GER
F
INDICATES GEAR/GYRO
SWITCH SELCTION FUNCTION
H : HOLD SWITCH
A : AILERON DUAL RATE SWITCH
E : ELEVATOR DUAL RATE SWITCH
F : FLIGHT MODE SWITCH
CHAPTER 6:FUNCTIONS
•
Helicopter continued
The XP652 gear/gyro switch selection function
enables the dual rate values of the gyro to be
combined with one of four switches (flight mode,
throttle hold, aileron dual rate, elevator dual rate).
This feature is for use with gyros that offer a dual rate
sensitivity adjustment such as the JRNEJ-900 Piezo Gyro
(JRPG900). The most common use for this feature
would be to combine the gyro dual rate adjustment
with the flight mode switch. This would then
automatically alter the gyro sensitivity from normal
(hover) to flight (forward flight) when the flight mode
switch is in use.
1. Press the MODE and CHANNEL buttons
simultaneously and hold.
2. Turn on the transmitter to enter the system mode.
3. Press the MODE button until GER appears on the
screen.
4. Press the INCREASE button to select the switch
you prefer to use for the operation of the gyro
sensitivity.
5. Press the MODE button to access the model
selection function.
6. To exit, press the MODE and CHANNEL buttons
simultaneously.
GEAR/GYRO SWITCH SELECTION
•
System Mode
6.4
Note: The remote gain lead from the gyro should be plugged into channel 5 (Gear) of the reciever.
