JR XP652 User Manual

Accessing the Servo Reversing Function
THR : THROTTLE
AIL : AILERON
ELE : ELEVATOR
RUD: RUDDER
GER: GEAR/GYRO
PIT : PITCH (HE ONLY)
CHANNEL
1
2
3
4
5
6
REV
◆
NORM
THR
–
+
MODE
ENTER
CHANNEL INCREASE
CLEAR
DECREASE
Press the INCREASE or DECREASE
button to change the servo direction.
Press the MODE
button until
REV
◆
NORM
appears on the
screen.
Press the
CHANNEL button
until the desired
channel appears
on the screen.
Left Right
High Pitch / Throttle
Low Pitch / Throttle
Left Right
Back
Forward
Forward
Back
Left Stick Direction (Mode II)
Left (Tail Rotor)
Up (More Pitch)
Down (Less Pitch)
Right (Tail Rotor)
Right Stick Direction (Mode II)
Left (Aileron)
Forward (Elevator)
Back (Elevator)
Right (Aileron)
Servo reversing is a very convenient function used
in the setup of a new aircraft. It is used to change
the direction of servo rotation in relation to the
corresponding stick movement. Servo reversing is
available for all 6 channels.
1. Turn on the transmitter.
2. Press the MODE and CHANNEL buttons
simultaneously to enter the function mode.
3. Press the MODE button until REV-NORM appears
on the screen.
4. Press the CHANNEL button until the desired
channel appears on the screen.
5. Press the INCREASE or DECREASE button to
change the servo direction.
6. Press the MODE button to access the dual rate
function.
7. To exit, press the MODE and CHANNEL buttons
simultaneously.
SERVO REVERSING
•
Function Mode
7.1
70
XP652 MANUAL Helicopter
CHAPTER 7:FUNCTIONS
•
Helicopter (Function Mode)
