XP652 MANUAL Airplane
MODE
ENTER
CHANNEL
HO = ALL SERVOS HOLD
0.3 = 1/3 SECOND TIME DELAY
0.5 = 1/2 SECOND TIME DELAY
1.0 = 1 SECOND TIME DELAY
HO
FST
Setting Fail-Safe/Hold Time Delay/Memory In Z-PCM Modulation
Press either the + or - buttons
to select the desired time delay.
INCREASE
CLEAR
+–
DECREASE
HOLD
0.3 SECONDS
0.5 SECONDS
1.0 SECONDS
1. After accessing the Fail-Safe Function, it is now
time to adjust the Fail-Safe Time Presets.
2. Select among the three time delays (0.3, 0.5, or 1.0
seconds) by pressing either the + or - buttons
until the desired setting appears on the screen.
Note: If Hold position is selected (HO) this
function/screen will not be present.
1. Press the MODE button until FSM appears on the
screen.
2. Set all controls to the desired fail-safe position,
then press the + and - buttons simultaneously. A
high pitch beep sound will confirm that the preset
positions have been entered.
3. Hold the transmitter sticks in the position that
you want the servos to assume during signal loss
conditions. You can determine fail-safe preset
positions for the other channels by placing the
control knobs and switches in the positions that
you want them to assume during interference.
4. With the sticks, switches and control knobs in
the fail-safe positions, press the + and - keys
simultaneously. This will enter these locations as
the fail-safe memory settings. A high pitched
beep will indicate that this setting has been
stored.
5. To confirm that the input of data was successful,
switch the transmitter OFF. The controls will move
to the input locations. If not, repeat step 4 again.
6. To exit the Fail-Safe Function, press the MODE
and CHANNEL buttons simultaneously.
Note: These preset positions remain stored in the
transmitter’s memory until both the transmitter
battery pack and the lithium back-up battery have
been removed (or until data reset has been
performed). Therefore, you do not have to reset the
fail-safe each time you fly. Should you want to re-
adjust the fail-safe presets, access the Fail-Safe
Function and adjust the presets as you have
just done. The transmitter automatically recalls the
settings for the last fail-safe adjustment.
MODE
ENTER
CHANNEL
CL WILL FLASH WHEN FAIL-SAFE
SERVO POSITIONS ARE
ENTERED.
C
L
FS
M
Press the + or - buttons
simultaneously to store the fail-
safe servo presets.
INCREASE
CLEAR
+–
DECREASE
FAIL-SAFE/HOLD FUNCTION IN Z-PCM MODULATION
6.9
Setting Servo Position Presets
To Next Page
