The XP652 in aircraft mode offers three (3)
programmable mixes to be used for a number of
different purposes. The functions allow mixing any
one channel to any other channel.
The mix can remain ON at all times, or be switched
OFF in flight using a number of different
switches. (Refer to Chart A). Each channel is identified
by channel numbers 1-6 (i.e., 2 = aileron, 4 = rudder,
etc. — See Chart B) The channel appearing first is
known as the “master channel,” or the channel to
which you want to mix. The second channel is known
as the “slave channel,” or the channel that is being
mixed into the master channel. For example, AILE-
RUDD would indicate aileron to rudder mixing. Each
time the aileron stick is moved, the aileron will deflect,
and the rudder will automatically move in the
direction and to the value input. Mixing is
proportional, so small inputs of the master channel
will produce small outputs of the slave
channel. Each programmable mix has a mixing “offset.”
The purpose of the mixing offset is to redefine the
neutral position of the slave channel.
PROGRAMMABLE MIXING (A,B,C)
•
Function Mode
7.10
Accessing the Programmable Mixing Function
1. Turn on the transmitter
2. Press theMODE and CHANNEL buttons
simultaneously to enter the Function Mode
3. Press the MODE button until MIX A11 appears at
the top right corner of the screen. This is Program
Mix A. Pressing the MODE button again will select
mixes B and C.
A B C
ON ON ON
F1 F1 F1
A A
E E
FO
5
MIX
Chart A Switch Selection
SWITCH
Always ON
Flap/Mix Switch
Position 1 ON
Aileron DIR Switch
Elevator DIR Switch
Flap/Mix Switch
Position O ON
Gear/Mix Switch
FUNCTION
Throttle
Aileron
Elevator
Rudder
Gear
Flap
Chart B Channel Numbers
CHANNEL NUMBER
1
2
3
4
5
6
MODE
ENTER
CHANNEL
0
%
AII
Press the MODE button until
MIX A11 appears
CURRENT MIX
CURRENT
MIX
CHANNELS
INCREASE
CLEAR
MIX
+–
DECREASE
45
XP652 MANUAL Airplane
