FX-1/FX-1R Maintenance Manual
(3) Disconnect the FPC on the LCD side and replace the LCD with a new one.
Always insert or remove the FPC with the FPC connector lock released.
Lock status
Unlock status
(4) Stick the LCD protector with the upper left corner of the LCD used as reference.
(5) Assemble the components in the reverse order of disassembly.
13-47
Rev. 2.00
