KE-2050/KE-2060, KE-2050R/2055R/KE-2060R Maintenance Manual
1-22
(2) Detach the head cover. Then cut and remove the tie-up band.
FC case cover
Figure 1-8-1-3
(3) Cut and remove the X-axis frame side (plastic rail bracket A) of X-axis plastic rail, the cable
clamp X and the tie-up band.
Plastic rail bracket A
Cable clamp X
Figure 1-8-1-4
(4) Detach the cover of the cable bearer and remove the cable to be replaced.
Rev. 2.00
