CHAPTER 21
Replacing Fan Trays
•
Removing a CTP2000 Fan Tray on page 125
•
Installing a CTP2000 Fan Tray on page 125
Removing a CTP2000 Fan Tray
To remove a fan tray:
1. With an appropriate screwdriver, loosen the captive screws located at the corners of
the fan tray.
WARNING: Do not place your fingers near the fans when removing the
fan tray. The blades might still be moving.
2. Gently pull the fan tray out. Place one hand under the fan tray and the other on the
front handle, and continue to pull it out of the chassis.
Use two hands to hold the fan tray after it comes out of the chassis.
Related
Documentation
Installing a CTP2000 Fan Tray on page 125•
Installing a CTP2000 Fan Tray
To install the fan tray:
1. With two hands hold the tray vertically so that the captive screws point toward you.
2. Place the side edge of the tray housing in the fan tray compartment, and push toward
the back of the chassis until the tray stops.
An electrical connector on the back of the fan tray pairs with an electrical connector
at the back of the shelf.
3. With an appropriate screwdriver, tighten the captive screws.
Alternate between screws when tightening them to ensure that the electrical
connectors at the back of the tray fit tightly.
125Copyright © 2017, Juniper Networks, Inc.
