Table 15: CTP2000 FXS Connector Pinouts on the RTM (continued)

PinSignalSignalPin

35Port 9 TPort 9 R10

36Port 10 TPort 10 R11

37Port 11 TPort 11 R12

38Port 12 TPort 12 R13

39Port 13 TPort 13 R14

40Port 14 TPort 14 R15

41Port 15 TPort 15 R16

42Port 16 TPort 16 R17

43Port 17 TPort 17 R18

44Port 18 TPort 18 R19

45Port 19 TPort 19 R20

46Port 20 TPort 20 R21

47Port 21 TPort 21 R22

48Port 22 TPort 22 R23

49Port 23 TPort 23 R24

FXO Connector Pinouts

The RTM for the CTP2000 2W-FXO interface module uses a RJ-21 25-pair Telco connector

labeled A. The A connector has 24 FXS ports.

FXO T is connected to FXS R; FXO T is connected to FXS T.

Table 16 on page 47 lists the RTM pinouts for the FXO module.

Table 16: CTP2000 FXO Connector Pinouts on the RTM

PinSignalSignalPin

26Port 0 RPort 0 T1

28Port 1 RPort 1 T3

30Port 2 RPort 2 T5

Chapter 6: Cable and Pinout Specifications
