Table 19: CTP2000 Serial DTE Cable Pinouts (continued)
DB-25J1 SCSICable
P3-2145
P3-896
P3-1046
P3-1197
P3-2447
P3-1898
P3-948
P3-1799
P3-2549
P3-7100
P3-150
Related
Documentation
CTP2000 Serial Interface Modules on page 11•
• CTP2000 FXS and FXO Interface Module Cables and Pinouts on page 45
• CTP2000 Series Console Cable Pinouts on page 58
CTP2000 Series Console Cable Pinouts
The console port CTP2008, CTP2024, and CTP2056 devices with the new PP833
processor uses a USB-type connector located on the right of the PP833 faceplate labelled
“RS-232”. CTP2000 series devices with the PP310 and PP332 processors use an RJ-45
connected to the COM2 port. This cable must be connected during the first boot process.
Use a shielded cable for the COM2 port on the CTP2056 device. Figure 29 on page 59
displays the console cable pin configurations for CTP2000 series devices with the PP310
and PP332 processors. On the left is the RJ-45 connector, and on the right is the DB-9
connector with the pin numbering indicated.
The console connections are configured to the following parameters:
•
Speed: 9600 bps
•
Data bits: 8
•
Stop bits: 1
Copyright © 2017, Juniper Networks, Inc.58
