Table 16: CTP2000 FXO Connector Pinouts on the RTM (continued)
PinSignalSignalPin
32Port 3 RPort 3 T7
34Port 4 RPort 4 T9
36Port 5 RPort 5 T11
38Port 6 RPort 6 T13
40Port 7 RPort 7 T15
42Port 8 RPort 8 T17
44Port 9 RPort 9 T19
46Port 10 RPort 10 T21
48Port 11 RPort 11 T23
Related
Documentation
CTP2000 2W-FXS and 2W-FXO Interface Modules on page 19•
• CTP2000 4WE&M Interface Connector Pinouts on page 43
• CTP2000 Series Console Cable Pinouts on page 58
• CTP Fast Ethernet and Power Cables on page 63
T1/E1 Interface Module Pinouts
Table 17 on page 48 lists the T1/E1 interface module pinouts for the RJ-45 connector.
Table 17: T1/E1 Interface Module—RJ-45 Connector Pinout
SignalRJ-45 Pin
RX Ring1
RX Tip2
–3
TX Ring4
TX Tip5
–6
–7
Copyright © 2017, Juniper Networks, Inc.48
