Chassis Physical Specifications for EX3200 and EX4200 Switches
The EX3200 and EX4200 switch chassis is a rigid sheet-metal structure that houses the
hardware components. Table 3 on page 7 summarizes the physical specifications of
the EX3200 and EX4200 switch chassis.
Table 3: Physical Specifications of the EX3200 and EX4200 Switch Chassis
ValueDescription
1.75 in. (4.45 cm)Chassis height
•
17.25 in. (43.82 cm)
•
19 in. (48.2 cm) with mounting brackets attached
Chassis width
•
Without power supply installed—17 in. (43.18 cm)
•
With power supply installed:
•
320 W AC power supply or 190 W DC power supply installed—17 in. (43.18 cm)
•
600 W or 930 W AC power supply installed—19.25 in. (48.9 cm)
Chassis depth
•
EX3200 switch with 1 power supply: 15–17 lb (6.8–7.7 kg)
•
EX4200 switch with 1 power supply: 16–18 lb (7.2–8.2 kg)
•
320 W AC power supply: 2.5 lb (1.1 kg)
•
600 W and 930 W AC power supplies: 3.1 lb (1.4 kg)
•
190 W DC power supply: 2.5 lb (1.1 kg)
Weight
Related Topics Rack Requirements for EX3200 and EX4200 Switches on page 93•
• Cabinet Requirements for EX3200 and EX4200 Switches on page 94
• Mounting an EX3200 or EX4200 Switch on page 120
• Installing and Connecting an EX3200 or EX4200 Switch on page 117
• Installing and Removing EX3200 and EX4200 Switch Hardware Components on
page 131
Front Panel of an EX3200 Switch
The front panel of an EX3200 switch consists of the following components:
•
10/100/1000Base-T Gigabit Ethernet ports, some or all of which are enabled forPower
over Ethernet (PoE)
•
Uplink module ports—SFP, SFP+, or XFP ports (The uplink module is an optional
feature.)
