• See Rear Panel of an EX3200 Switch on page 8 for port location.
• See Rear Panel of an EX4200 Switch on page 11 for port location.
• See Front Panel of an EX4500 Switch for port location.
• See Switch Fabric and Routing Engine (SRE) Module in an EX8208 Switch for port
location.
• See Routing Engine (RE) Module in an EX8216 Switch for port location.
• Connecting an EX Series Switch to a Management Console on page 153
Management Port Connector Pinout Information for an EX3200 or EX4200 Switch
The management port on an EX3200 or EX4200 switch uses an RJ-45 connector to
connect to a management device for out-of-band management.
The port uses an autosensing RJ-45 connector to support a 10/100/1000Base-T
connection. Two LEDs on the port indicate link/activity on the port and the administrative
status of the port. See “Management Port LEDs in EX3200 and EX4200 Switches” on
page 25.
Table 17 on page 42 provides the pinout information of the RJ-45 connector. An RJ-45
cable, with a connector attached, is supplied with the switch.
Table 17: Management Port Connector Pinout Information for EX3200 and EX4200 Switches
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1-2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3-5
Transmit/receive data pair 2TRP2-6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4-8
Related Topics See Rear Panel of an EX3200 Switch on page 8 for port location.•
• See Rear Panel of an EX4200 Switch on page 11 for port location.
• Connecting an EX Series Switch toa Network forOut-of-Band Management on page 152
Copyright © 2010, Juniper Networks, Inc.42
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches
