Figure 17: 320 W AC Power Supply in EX3200 and EX4200 Switches

Figure 18: 600 W and 930 W AC Power Supplies in EX3200 and EX4200

Switches

Figure 19: DC Power Supply in EX3200 and EX4200 Switches

Table 11 on page 28 lists the minimum power requirements for each model of EX3200

switch. The maximum power available to each PoE port is 15.4 W.

Table 11: Minimum Power Requirements for an EX3200 Switch

Minimum Power RequirementNumber of PoE-enabled PortsModel Number

320 W8EX3200-24T
