Table 21: Optical Interface Support for Gigabit Ethernet XFP Transceivers in EX3200 and EX4200

Switches (continued)

SpecificationsEthernet Standard

EX-XFP-10GE-ERModel Number10GBase-ER

10 GbpsRate

LCConnector Type

DualFiber Count

1550 nmTransmitter Wavelength

–5 dBmMinimum Launch Power

2 dBmMaximum Launch Power

–22 dBmMinimum Receiver Sensitivity

–1 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

40 km (24.8 miles)Distance

AvailableDOM Support

Junos OS for EX Series switches, Release 9.0 or laterSoftware required
